Makita DTC104 Cordless Cable Cutter

Name: Cordless Cable Cutter
Brand: Makita

Makita · Model DTC104

DTC104

Request a quotation

Makita Cordless Cable Cutter

Makita DTC104 is listed in the manufacturer's cordless cable cutter range. OEM technical data: Output force: 120 kN; Max blade opening width : 105 mm (4-1/8″).

Official model: DTC104

Required quantityEnquire on WhatsApp

Pricing, model selection, stock and delivery are confirmed in your quotation.

Technical information

Product type	Cordless Cable Cutter
Output force	120 kN
Max blade opening width	105 mm (4-1/8″)
Blade shape	Scissor-style
Max cable cutting capacity	Polyethylene power cable: ø72 mm (4 x 325 mm²) PVC insulated multi-core cable: ø77 mm (3 x 325 mm²) Annealed copper wire: ø105 mm (1,300 mm²) Hard-drawn copper wire: ø90 mm (1,300 mm²) Aluminum wire: ø105 mm (1,300 mm²) ACSR: NO
Housing shape	Straight
Automatic reverse function	YES (Reverse rotation of motor)
Dimensions (L x W x H)	718 x 123 x 267 mm (28-1/4 x 4-7/8 x 10-1/2″)
Dimensions (Battery)	BL1860B
Net weight	10.2 – 10.5 kg
Net weight (Battery)	BL1815N – BL1860B

Key features

Output force: 120 kN
Max blade opening width : 105 mm (4-1/8″)
Blade shape: Scissor-style
Max cable cutting capacity: Polyethylene power cable: ø72 mm (4 x 325 mm²) PVC insulated multi-core cable: ø77 mm (3 x 325 mm²) Annealed copper wire: ø105 mm (1,300 mm²) Hard-drawn copper wire: ø90 mm (1,300 mm²) Aluminum wire: ø105 mm (1,300 mm²) ACSR: NO
Housing shape: Straight
